MS-Terminator B760M D5 WIFI 6E V2 Intel Core DDR5 Motherboard – Black

Model:

• • • MAXSUN TERMINATOR B760M D5 WIFI 6E

Chipset:

• • • Intel® B760 High-Speed Chipset

CPU Support:

• • • LGA 1700 Socket
    • Supports 12th / 13th / 14th Gen Intel® Core™ Processors
    • Supports Pentium® Gold & Celeron® Processors

Memory:

• • • 4 × DDR5 DIMM Slots
    • Max Memory: 192GB
    • Dual Channel Architecture
    • DDR5 7600+(OC) / 7200(OC) / 7000(OC) / 6800(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5800(OC) / 5600(JEDEC) / 5400(JEDEC) / 5200(JEDEC) / 5000(JEDEC) / 4800(JEDEC)

Onboard Graphics (CPU Dependent):

• • • 1 × DisplayPort 1.4
    • 1 × HDMI™ Port (Up to 4K @30Hz)
    • Display resolution may vary by CPU model

Expansion Slots:

• • • 1 × PCIe 5.0 x16 Slot
    • 1 × PCIe 3.0 x4 Slot

Storage:

• • • 3 × M.2 Slots (2242 / 2280 PCIe x4 / x2 SSD Supported)
    • 4 × SATA 6Gb/s Ports
    • RAID 0 / 1 / 5 / 10 (SATA)

USB:

• • • 2 × USB 3.2 Gen 2 (Rear)
    • 1 × USB Type-C® (USB 3.2 Gen 2×2)
    • USB 3.2 Gen 1 Internal Header
    • 6 × USB 2.0 Ports
    • Additional USB 2.0 Internal Headers

LAN:

• • • Realtek® RTL8125BG 2.5G LAN

Audio:

• • • Realtek® ALC897 Codec
    • 5.1 Channel High Definition Audio

Display Output:

• • • 1 × HDMI 2.0 (Up to 4096×2160 @60Hz, HDCP 2.2)
    • 1 × DisplayPort (Up to 4096×2160 @60Hz)

Operating System:

• • • Windows® 11 64-bit
    • Windows® 10 64-bit

Form Factor:

• • Micro-ATX (245mm × 245mm)
